Specifications
ACAR 5.56/223
ACAR 7.62/308
16″ Barrel
20″ Barrel
Overall Length
730 mm
860 mm
960 mm
Weight
2.80Kg
4.25Kg
4.40Kg
Calibre
5.56 NATO and .223 Remington
.308 Winchester / 7.62 NATO
.308 Winchester / 7.62 NATO
Barrel Length
11″
16″ (508mm)
20″ (508mm)
Sustained rate of fire
50 Rounds per minute
50 Rounds per minute
50 Rounds per minute
Rifling
6 Lands & Grooves, 1:8″ RH Twist
6 Lands & Grooves, 1:10″ RH Twist
6 Lands & Grooves, 1:10″ RH Twist
Trigger Pull
Lithgow Arms single stage trigger
–
–
Trigger Pull (Semi)
5 lbs. (single stage trigger)
3.2-5.0 lbs. (1st stage – optional trigger)
0.5-1.5 lbs. (2nd stage – optional trigger)
3.2-5.0 lbs. (1st stage – optional trigger)
0.5-1.5 lbs. (2nd stage – optional trigger)
5 lbs. (single stage trigger)
3.2-5.0 lbs. (1st stage – optional trigger)
0.5-1.5 lbs. (2nd stage – optional trigger)
3.2-5.0 lbs. (1st stage – optional trigger)
0.5-1.5 lbs. (2nd stage – optional trigger)
5 lbs. (single stage trigger)
3.2-5.0 lbs. (1st stage – optional trigger)
0.5-1.5 lbs. (2nd stage – optional trigger)
3.2-5.0 lbs. (1st stage – optional trigger)
0.5-1.5 lbs. (2nd stage – optional trigger)
Range
> 500 meters
> 700 meters
> 700 meters
Barrels
Barrels from 9″ to 18″ and full auto/semi auto available
Barrels from 14″ to 20″ and full auto/semi auto available
